Code: SIP06289
SIP ISBD5.5/270 Industrial Electric Compressor | 5.5hp (4.1kW) | 270 Litre
Capacity
Code: SIP06289
SIP ISBD5.5/270 Industrial Electric Compressor | 5.5hp (4.1kW) | 270 Litre
Capacity
NEW PRODUCT
£1,931.03
Price / pack (Excl. VAT)
Delivery time: 4-5 Working Days
Good reasons to purchase products from us
- Next day delivery available, in stock products only
- Find a lower price & we'll match it
- Large Project? Call for site visit & quote
We will be happy to help you
0333 200 5299
Mon to Thurs 8am - 5:30pm
Friday 8am - 4:30pm
Excluding Bank Holidays
Friday 8am - 4:30pm
Excluding Bank Holidays
£1,931.03
Price / pack (Excl. VAT)
Product description
The SIP Industrial Electric Compressor is a powerful belt-driven workhorse compressor built to last and designed for consistently high performance plus superior compressed air production. Fitted with large interstage coolers, this compressor provides cooler air ideal for a variety of demanding environments.
- A must-have premium compressor for heavy-duty industrial applications
- Oil-lubricated industrial-grade belt-driven compressor
- Large interstage coolers for cooler air and reduced moisture
- Long-stroke cast iron cylinders for slower running and longer life
- SIP 10 year receiver anti-corrosion warranty
Specifications
| Specifications | SIP06289 | SIP06291 | SIP06295 | SIP06297 |
|---|---|---|---|---|
| Input Supply: | 400v (20A) 3-PHASE | 400v (20A) 3-PHASE | 400v (20A) 3-PHASE | 400v (32A) 3-PHASE |
| Motor Power: | 5.5hp (4.1kW) | 7.5hp (5.6kW) | 10hp (7.5kW) | 15hp (11.2kW) |
| Receiver Size: | 270ltr | 270ltr | 270ltr | 500ltr |
| Piston Displacement: | 23.50CFM (666ltr/min) | 31.00CFM (878ltr/min) | 38.00CFM (1076ltr/min) | 61.50CFM (1744ltr/min) |
| Free Air Delivery (FAD): | 15.50CFM (439ltr/min) | 20.50CFM (580ltr/min) | 25.00CFM (708ltr/min) | 40.70CFM (1153ltr/min) |
| Max. Air Pressure: | 160psi (11bar) | 160psi (11bar) | 160psi (11bar) | 160psi (11bar) |
| Working Speed: | 1290rpm | 1200rpm | 1000rpm | 1200rpm |
| No. of Cylinders: | 2 cylinders | 2 cylinders | 2 cylinders | 4 cylinders |
| No. of Stages: | 2 stages | 2 stages | 2 stages | 2 stages |
| Net Weight: | 166.00kg | 190.00kg | 220.00kg | 313.00kg |
| Packaged Dimensions: | 1340(H) x 1640(W) x 560mm(D) | 1320(H) x 1640(W) x 560mm(D) | 1340(H) x 1640(W) x 560mm(D) | 1680(H) x 2270(W) x 860mm(D) |
