Code: HR186GGWB62

BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes | 1770h x 1800w x 600d mm | Graphite Grey | 4 Levels | 12x 62L Boxes | 500kg UDL

BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes
BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes, BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes, BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes | 1770h x 1800w x 600d mm | Graphite Grey | 4 Levels | 12x 62L Boxes | 500kg UDL-0
BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes (Product illustration 2)-1
BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes, BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes, BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes | 1770h x 2400w x 600d mm | Blue | 4 Levels | 15x 62L Boxes | 450kg UDL-2
BiGDUG Garage Heavy Duty Shelving Kit With Wham Bam Recycled Storage Boxes (Product illustration 4)-3
Width [mm]
Colour
Code: HR186GGWB62
Product description

Get ready to transform your storage game with this heavy duty duo! Our best-selling BiGDUG Garage Heavy Duty Shelving combined with Wham Bam Heavy Duty Recycled Storage Boxes create a durable and long-lasting storage solution.

  • Load capacity of up to 500kg UDL* per shelf
  • Fitted with 4 x adjustable MDF shelves and supports
  • Powder-coated European steel frame manufactured to ISO 9001 with a 5-year warranty
  • Simple boltless assembly, just tap together with a rubber mallet
  • Storage boxes are 100% recycled and tested to withstand weights of up to 380kg
  • Adjustable levels can be raised or lowered every 50mm
  • No cross-bracing ensures productive double-sided access
  • The boxes have an impressive resilience to impact damage and cold temperatures
  • The snap-on lids offer a peace of mind, while the integrated tie-wrap holes offer an extra level of security
  • Also have been designed to nest and stack, allowing for convenient organization and efficient use of space if needed

*UDL = Uniformly Distributed Load

Shelving Specifications

Data Field     1800mm Wide         2000mm Wide         2400mm Wide
Upright Type One Piece One Piece One Piece
Upright Steel Thickness 0.7mm 0.7mm 0.7mm
Beam Steel Thickness 0.7mm 0.7mm 0.7mm
Shelf Adjustment Increments 50mm 50mm 50mm
Shelf Height 82mm 82mm 82mm
MDF Thickness 6.5mm 6.5mm 6.5mm
Total Bay Capacity 2000kg 2000kg 1800kg
Clear Width 1705mm 1905mm 2305mm
Extra Levels Available N N N
No. Storage Boxes Included 12 12 15

Shelving Fitting Guide

Please check our guides for each range when planning your shelving space.

Nominal Shelf Width mm: Clear Entry mm: Initial Bay External mm: Next Bay External mm:
1800 1705 1805 1810
2000 1905 2005 2010
2400 2305 2405 2410

External Height = H+15       Pitch = 38.1

Clear height between shelves = No. x pitch1 -94

All dimensions in Millimetres

Strorage Box Specifications

Stock Code Capacity External Dimensions Internal Dimensions
WBWMR62 62 Litres 370h x 400w x 600d mm 340h x 320w x 470d mm
‌
‌
‌
‌
‌
